Duplex Stainless Steel Tube

Size Range:OD:6mm-610mm,Thickness: O.Smm-25.4mm.Max length: 30000mm

Standard:GB/ 21833,GB/T14976,GB 13296, ASTMA789,ASTMA790,ASTMA450,ASTMA999,EN 10216-5, JIS G3459

Materials:S31803、S32205、S32750、S32760

Duplex stainless steel tube(Seamless tube and welded tube) can be divided into four types: Low alloy, medium alloy,high alloy and super duplex stainless steel Type. The main Characteristic of the Duplex stainless steel tube is that its yield strength can reach 400-550MPa, Which is twice that of ardinary stainless steel. so it can save material and reduce equipment manufacturing costs. in terms of corrosion resistance, especially for poor conditions of the medium (such as seawater and high chloride ion content),the resistance to pitting,crevice corrosion, stress corrosion, and corrosion fatigue of duplex stainless steels is significantly better than that of ordinary austenite, as good as high-alloy austenitic stainless steels.

Xunhong steel co.,ltd can provide duplex stainless steel pipes and plates of various standards and grades, passed ISO9001,SGS and other certificates,accept third-party testing, has complete testing and testing facilities, from produrct development raw material supply, production proces management, etc. in accordance with international quality The system standards are standardized to provide customers with satisfactory pre-sale, In-sale and after sale service. Feel free to contact us anytime

ASTM A789/SA789 - Standard Specification for Seamless and Welded Ferritic/Austenitic  Stainless Steel Tubing for General Service

ASTM A790/SA790 - Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Pipe

ASTM A928 (ASME SA928) - Standard Specification for Ferritic/Austenitic (Duplex) Stainless Steel Pipe Electric Fusion Welded with Addition of Filler Metal

Steel Grade:

Duplex 2507 (UNS S32750) is a super duplex stainless steel with 25% chromium, 4% molybdenum, and 7% nickel designed.

Duplex 2205 (UNS S31803), or Avesta Sheffield 2205 is a ferritic-austenitic stainless steel.

SUPER DUPLEX UNS S32760 - is a super duplex stainless steel, so-called due to its higher Chromium and Molybdenum content.


Chemical Composition for Duplex Stainless Steel Pipe(%)


CMnPSSiCrNiMoNCu
UNS S321010.03max2.0max0.03max0.03max1.0max20.0-23.01.0-3.00.6max0.05-0.171.0max
UNS S318030.03max2.0max0.03max0.02max1.0max21.0-23.04.5-6.52.5-3.50.08-0.20/
UNS S322050.03max2.0max0.03max0.02max1.0max22.0-23.04.5-6.53.0-3.50.14-0.20/
UNS S327500.03max1.2max0.035max0.02max0.8max24.0-26.06.0-8.03.0-5.00.24-0.320.5max
GradeTensile   strength, Min Ksi(MPa)Yield   strength, Min Ksi(MPa)Elongation   in2 in,or 50mm,min,%Hardeness,Max   Brinell
S3180390(620)65(450)25290
S3220595(655)70(485)25290
S3150092(630)64(440)30290
S32550110(760)80(550)15297
S31200100(690)65(450)25280
S31260100(690)65(450)25290
S3200190(620)65(450)25290
S32304100(690)65(450)25290
S32750116(800)80(550)15310
S32760109(750)80(550)25300
S32950100(690)70(480)20290
S32520112(770)80(550)25310
