Subsea Pipeline Comprehensive Service(CNOOC)
Coating Type:FBE/2FBE/3LPE/3LPP Coating
Specification:
FBE/2FBE/3LPE/3LPP:Pipe diameter: Φ168-1422mm (6-56 inch)
Pipe concrete counterweight coating process (CWC):Pipe diameter: Φ168-1422mm( 6-56inch)，Coating thickness: 35-150mm，Coating density:2240-3400kg/m3
Thermal insulation coating-a. Polyurethane spray polyethylene extrusion coating process (PUF):Φ168-813mm (6-32inch)
Thermal insulation coating-b. Polyurethane casting process
Thermal insulation coating-c. GSPU wet insulation process:Φ168-813mm (6-32 inch), coating thickness: 30-120mm
Thermal insulation coating-d. Silica airgel felt steel sheathed steel thermal insulation process:
Main Products Description
| Core Product | Size | Coating detail | Application | ||||||
| FBE 2FBE 2LPE 3LPE/PP Coated Pipe | Φ168-1422mm(6-56inch) | FBE 2FBE 2LPE 3LPE/PP | For most oil and gas pipelines and water pipelines | ||||||
| Concrete weight coated pipe | Φ168-1422mm(6-56inch) | Coating Thickness:35-150mm,Coating Density:2240-3400kg/m3 | For submarine gas pipelines,lakes,cross-section pipelines etc | ||||||
| Insulation coating pipe | PUF,Polyurethane-coated | Φ168-813mm(6-32inch)or customized | Single-layer insulation jacket pipe,Steel-Sheathed steel insulation pipe | Land and submarine oil pipelines | |||||
| GSPU | Φ168-813mm(6-32inch)and larger diameter | Coating Thickness:30-120mm | Deepwater oil pipelines,with a maximum depth of more than 1500 meters | ||||||
| Polyurethane casting process | |||||||||
| Silica airgel felt steel sheathed steel thermal insulation process | Submarine double-layer insulated pipe | ||||||||
