ASTM A213 Steel Pipe

Main grades: ASTM A213 T5, T5b, T9, T11, T91 and T22

Size range:

NPS 1/4" to NPS 24"

Wall Thickness - Schedules 40 through 160, STD, XS, XXS

Unscheduled heavy wall pipe thicknesses available up to 4 inches.

Xunhong steel co.,ltd is the leading ASTM A213 alloy steel tube manufacturers and suppliers, if you want to buy or import A213/SA213 T2, A213/SA213 T5, A213/SA213 T9, A213/SA213 T11,A213/SA213 T12, A213/SA213 T22, A213/SA213 T91, A213/SA213 T92 alloy steel tube,ASTM A213 Alloy Tubes are been widely used in high temperature services especially for the boiler and superheater.

NPS,inch	Outside Diameter(mm)	Wall Thickness(mm)	Max,Length(M)
1/8	10.3	1,24; 1,73; 2,40	12
1/4	13.7	1,65;2,24; 3,02
3/8	17.1	1,65;2,31; 3.20
1/2	21.3	1,65; 2,11; 2,77; 3,73
3/4	26.7	1,65; 2,11; 2,87; 3,91
1	33.4	1,65; 2,77; 3,38; 4,55	10
1 1/4	42.4	1,65;277; 3,56;4.85
1 1/2	48.3	2,77；3,68；5.08
2	60.3	3,91; 5,54	7
2 1/2	73.0	5,16； 7,01

ASTM A213 Standard Specification for Seamless ferritic and austenitic alloy-steel boiler,Superheater,heat-exchanger tubes

Chemical Composition

Grade	UNS Designation	C	Mn	P	S	Si
T2	K11547	0.10-0.20	0.30-0.61	0.025	0.025B	0.10-0.30
T5	K41545	0.15	0.30-0.60	0.025	0.025	0.5
T5b	K51545	0.15	0.30-0.60	0.025	0.025	1.00-2.00
T5c	K41245	0.12	0.30-0.60	0.025	0.025	0.5
T9	K90941	0.15	0.30-0.60	0.025	0.025	0.25-1.00
T11	K11597	0.05-0.15	0.30-0.60	0.025	0.025	0.50-1.00
T12	K11562	0.05-0.15	0.30-0.61	0.025	0.025B	0.5
T17	K12047	0.15-0.25	0.30-0.61	0.025	0.025	0.15-0.35
T21	K31545	0.05-0.15	0.30-0.60	0.025	0.025	0.50-1.00
T22	K21590	0.05-0.15	0.30-0.60	0.025	0.025	0.5
T23	K40712	0.04-0.10	0.30-0.60	0.03	0.01	0.5
T24	K30736	0.05-0.10	0.30-0.70	0.02	0.01	0.15-0.45
T36	K21001	0.10-0.17	0.80-1.20	0.03	0.025	0.25-0.50
T91	K90901	0.07-0.14	0.30-0.60	0.02	0.01	0.20-0.50
T92	K92460	0.07-0.13	0.30-0.60	0.02	0.01	0.5
T122	K91271	0.07-0.14	0.7	0.02	0.01	0.5
T911	K91061	0.09-0.13	0.30-0.60	0.02	0.01	0.10-0.50

Mechanical Properties

Grade	Tensile strength(Mpa)	Yield Point(Mpa)not less than	Elongation(%)not less than	Impact(J)not less than	Hardness not less than
A213 T2/SA213 T2	≥415	205	-	"	85HRB
A213 T11/SA213 T11	≥415	205	-	"	85HRB
A213 T22/SA213 T22	≥415	205	-	"	85HRB
A213 T23/SA213 T23	≥510	400	20	"	97HRB
A213 T24/SA213 T24	≥585	415	20	"	25HRB
A213 T91/SA213 T91	≥585	415	20	"	25HRB
A213 T911/SA213 T911	≥620	440	20	"	25HRB
A213 T22/SA213 T92	≥620	440	20	"	25HRB
A213 T122/SA213 T122	≥620	400	20		25HRB
TP304H	≥515	205	35		90HRB
TP316H	≥515	205	35		90HRB
TP321H	≥515	205	35		90HRB
TP347H	≥515	205	35		90HRB
S30432	≥590	235	35		95HRB
TP310HCbN	≥655	295	30		100HRB
