API 5L Line Pipe

Product Dimension:SMLS:Φ10.3-720 x 1.7-52mm; WELD:Φ219-2134 x 5-52mm

Standard:API SPEC 5L,ISO 3183,EN10208

Uses:For conveying gas,water and oil either in the oil or natural gas industries

Grades: API 5L Grade B, X42, X52,X56,X60,X65,X70,X80

Product Specification Level: PSL1, PSL2, onshore and offshore sour services.

Thickness Schedule: SCH 10, SCH 20, SCH 40, SCH STD, SCH 80, SCH XS, to SCH 160

Manufacturing Types: Seamless (Hot Rolled and Cold Rolled), Welded ERW (Electric resistance welded), SAW (Submerged Arc Welded) in LSAW, DSAW, SSAW.HSAW

Ends Type: Beveled ends, Plain ends

Length Range: SRL (Single Random Length), DRL (Double Random Length), 20 FT (6 meter), 40FT (12 meter)or customized

Surface Treatment: Natural, Varnished, Black painting, FBE, 3PE (3LPE),3PP, CWC (Concrete Weight Coated) CRA Clad or Lined

Standard	Type of pipe	Class	Grade
API SPEC 5L ISO 3183	SMLS	PLS1	L245B,L290X42,L320X46,L360X52,L390X56,L415X60,L450X65,L485X70
		PLS2	L245N BN,L290NX42N,L320NX46N,L360NX52N,L390NX56N,L415NX60N, L360QX52Q,L390QX56Q,L415QX60Q,L485Q
		PLS2 Sour environment	L245NS BNS,L290NSX42NS,L320NSX46NS,L360NSX52NS,L390NSX56NS, L415NSX60NS,L360QSX52QS,L390QSX56QS,L415QSX60QS,L485QS
	WELD	PLS1	L245B,L290X42,L320X46,L360X52,L390X56,L415X60,L450X65,L485X70
		PLS2	L245M BM,L290MX42M,L320MX46M,L360MX52M,L390MX56M,L415MX60M, L450MX65M,L485MX70M,L555MX80M
GB/T9711.1	SMLS	-	L245,L290.L320,L360
	WELD	-	L245,L290.L320,L360,L390,L415,L450,L485,L555
GB/T9711.2	SMLS	-	L24SNB,L290NB,L360NB,L415NB
	WELD	-	L245MB,L290MB,L360MB,L15MB,L450MB,L485MB,L555MB
GB/T9711.3	SMLS	Non-Sour Environment	L245MC,L290NC,L360NC
	WELD	Sour Environment	L245NCS,L290NCS,L360NCS
	SMLS	Non-Sour Environment	L290MC,L360MC,L415MC,L450MC,L485MC,L555MC
	WELD	Sour Environment	L290MCS,L360MCS,L415MCS,L450MCS,L480MCS

Chemical Analysis

Standard	Type of pipe	Class	Grade	C	Si	Mn	P	S	V	Nb	Ti
Standard	Type of pipe	Class	Grade	Max	Max	Max	Max	Max	Max	Max	Max
API SPEC 5L	SMLS	PLS1	L245B	0.28	0.4	1.2	0.03	0.03	-	-	0.04
			L290x42	0.28		1.3	0.03	0.03
			L320x46	0.28		1.4	0.03	0.03
			L360x52	0.28		1.4	0.03	0.03
			L390x56	0.28		1.4	0.03	0.03
			L415x60	0.28		1.4	0.03	0.03
			L450x65	0.28		1.4	0.03	0.03
			L485x70	0.28		1.4	0.03	0.03
			L245N BN	0.28		1.2	0.025	0.015
		PLS2	L290x42N	0.24	0.4	1.2	0.025	0.015	0.06	0.05	0.04
			L320Nx46N	0.24	0.4	1.4	0.025	0.015	0.07	0.05	0.04
			L360Nx52N	0.24	0.45	1.4	0.025	0.015	0.1	0.05	0.04
			L390Nx56N	0.24	0.45	1.4	0.025	0.015	0.1	0.05	0.04
			L415Nx60N	0.24	0.45	1.4	0.025	0.015	0.1	0.05	0.04
	WELD	PLS1	L245B	0.26	-	1.2	-	0.03	0.03	-	-
			L290x42	0.26	-	1.3	-	0.03	0.03	-	-
			L320x46	0.26	-	1.4	-	0.03	0.03	-	-
			L360x52	0.26	-	1.4	-	0.03	0.03	-	-
			L390x56	0.26	-	1.4	-	0.03	0.03	-	-
			L415x60	0.26	-	1.4	-	0.03	0.03	-	-
			L450x65	0.26	-	1.45	-	0.03	0.03	-	-
			L485x70	0.26	-	1.65	-	0.03	0.03	-	-
		PLS2	L245M BM	0.22	0.45	1.2	0.025	0.015	0.05	0.05	0.04
			L290Mx42M	0.22	0.45	1.3	0.025	0.015	0.05	0.05	0.04
			L320Mx46M	0.22	0.45	1.3	0.025	0.015	0.05	0.05	0.04
			L360Mx56M	0.22	0.45	1.4	0.025	0.015	-	-	-
			L390Mx56M	0.22	0.45	1.4	0.025	0.015	-	-	-
			L415Mx60M	0.12	0.45	1.6	0.025	0.015	-	-	-
			L450Mx65M	0.12	0.45	1.6	0.025	0.015	-	-	-
			L485Mx70M	0.12	0.45	1.7	0.025	0.015	-	-	-
			L555Mx80M	0.12	0.45	1.85	0.025	0.015	-	-	-

Mechanical Properties

Standard	Calss	Grade		Yield strength not less then(Mpa)	Tensile strength(Mpa)	Elongation (%)	Y.S/T.S
API SPEC 5L ISO 3183	PLS1	L245B	min	245	415	b	-
		L290x42	min	290	415	b	-
		L320x46	min	320	435	b	-
		L360x52	min	360	460	b	-
		L390x56	min	390	490	b	-
		L415x60	min	415	520	b	-
		L450x60	min	450	535	b	-
		L485x70	min	485	570	b	-
	PLS2	L245N BN	min	245	415	b	-
		L245M BM	max	450	760	b	0.93
		L290Nx42N	min	290	415	b	-
		L290Mx42M	max	495	760	b	0.93
		L320Nx46N	min	320	435	b	-
		L320Mx46M	max	525	760	b	0.93
		L360Nx52N	min	360	460	b	-
		L360Mx52M	max	530	760	b	0.93
		L390Nx56N	min	390	490	b	-
		L390Mx56M	max	545	760	b	0.93
		L415Nx60N	min	415	520	b	-
		L415Mx60M	max	565	760	b	0.93
		L450Mx65M	min	450	535	b	-
		L450Mx65M	max	600	760	b	0.93
		L485Mx70M	min	485	570	b	-
		L485Mx70M	max	635	760	b	0.93
		L555Mx80M	min	555	625	b	-
		L555Mx80M	max	705	825	b	0.93
