Size Range:
OD: 6mm-2020mm Thickness: 0.6mm-100mm.
Length:As customized requirement.
Material&Grades:
321, 304,310S,304L,316,316L, 316Ti, 317, 317L,347H, 2205,S31803,S32205, S32750,S32760.
Standards:
GB21833/T14976. GB13296.JIS G4303, JIS G4311, ASTM A959, BS/EN 1.4301, BS/EN 1.4845, BS /EN1.4306, BS/EN 1.4401, BS/EN 1.4571, ASTM A789/ A789 M,ASTM A928/ A928 M,ASTM A790/A790M,ASTM A249,JIS G17458, JIS3459, ASTM A269,ASTM 312, DIN 17455, ASTM A358, ASTM A450,ASTM A999
stainless steel welded pipes can be diviced into stainless steel welded pipes for mechanical structures and stainless steel welded pipes for fuid transportation according to their applications. Stainless steel welded pipes for mechanical structuresare mainly used for machinery, automobiles, bicycles, furniture, hotel and restaurant decoration and other mechanical parts and structural parts. Stainless steel welded steel pipes for fluid transportation are mainly used to transport low pressure corrosive media.
Xunhong steel co.,Ltd can provide duplex stainless steel welded pipes of various standards and grades, passed ISO9001 SGS and other certificates, accept third-party testing, has complete testing and testing facilities, from product development, raw material supply, production process management, etc. in accordance with international quality The system stancdards are standardized to provide customers with satisfactory pre-sale, in-sale and after-sale services. Feel free to contact us anytime
Product Name | Executive Standard | Dimension | Steel Code/Steel Grade | ||||||||||
Industrial Pipes | ASTM A312,A358,A778,JIS G3459 | OD: 1/4"-48" WT: SCH5S-SCH80S | TP304,TP304L,TP316L,SUS304TP | ||||||||||
Tubes for Boiler and Heat-Exchanger, General Service Tubing | ASTM A249,A269,JISG3463 | OD: 15.9-139.8mm WT: 1.6-5.0mm | TP304,TP304L,TP316L,SUS304TB | ||||||||||
Mechanical and Structural Tubes | ASTM A554,JIS G3446 | OD: 7.9-152.4mm WT: 0.5-6.5mm | MT304,MT304L,MT316L,MT430 Grade201, 202 as per mill's STD SUS304 | ||||||||||
Square Tubes | ASTM A554 | OD:12.7x12.7-150x150mm WT: 0.7-6.5mm | MT304,MT304L,MT316L, MT430 Grade201, 202 as per mill's STD | ||||||||||
Rectangular Tubes | ASTM A554 | OD:10x20-100x200mm WT:0.7-6.5mm | MT304,MT304L,MT316L, MT430 Grade201, 202 as per mill'S STD | ||||||||||
Sanitary Tubing | ASTM A270 | OD: 25.4-165.2mm WT: 0.8-3.05mm | TP304,TP304L,TP316L,SUS304TBS | ||||||||||
JIS G3447 | |||||||||||||
Large Gauge Pipes for Ordinary Piping | JIS G3448 | OD: 15.88-318.5mm WT: 0.8-3.0mm | SUS304TPD | ||||||||||
Large Diameter Pipes | JIS G3468 | OD: 14"-40" WT: SCH5S-SCH40S | SUS304TPY |
